| Model Number | LWL2-18-XX | LWL2-36-XX |
| Picture |
 |
|
| Performance |
|
|
| Data Sheet | download | download |
| Input Wattage | 18W | 36W |
| Input Voltage Range (V) | 85-265 | 85-265 |
| Delivered Lumens (lm) | 1600 lm | 3200 lm |
| Efficacy (lm/W) | 90 lm/W | 90 lm/W |
| Color Rendering Index (CRI) | 72 | 72 |
| Color Temperature (CCT) | 3000K/4000K/5000K/6000K/6500K | |
| Protection Ratio |
IP65 |
IP65 |
| Power Factor | ＞0.95 | ＞0.95 |
| MAX THD (%) | 15 | 15 |
| Min. Ambient Temp (°C) | -40 | -40 |
| Max. Ambient Temp (°C) | 50 | 50 |
| Dimming Control |
|
|
| Dimming compatible | N/A | N/A |
| 0-10V Dimming | N/A | N/A |
| Dimensions |
|
|
| Product Weight (kgs) | 0.15 | 0.27 |
| Product Height (mm) | 30 | 30 |
| Product Length (mm) | 615 | 1225 |
| Product Width (mm) |
55 |
55 |
| Longevity |
|
|
| Life time (Hours) | >30000 | >30000 |
| Warranty (Years) |
2 years |
2 years |
| Qualifications |
|
|
| EMC | Yes | Yes |
| INSULATION TESTING | 3.0 KV | 3.0 KV |
